4K UHD/50P to MP4
1.0-Type CMOS sensor
15x zoom
4K UHD/50P
Up to 150Mbps
Autofocus
Accurate and reliable autofocus
1.0-Type
CMOS sensor
1.0 - Type CMOS
RGB Primary Colour Filter
13.4 MP
8.29 MP
Approx. 0.1 lx to 100,000 lx, depending on settings
Approx. 1.4 lx, P Mode(shutter speed 1/25 sec.) (50.00P; with auto slow shutter On), Low Light Mode: Approx. 0.1 lx (shutter speed 1/2 sec.)
15x Optical (30x Advanced Zoom in Full HD)
Approx. 25.5 to 382.5 mm
10 mm at wide end, 60 cm across entire zooming range
3 densities: turret switched, motor-driven.
ND 1/4, ND 1/16, and ND 1/64.
Via Zoom Rocker Switch, Lens Control ring or Remote Control
Selectable. Variable or constant speed. Fast, Normal or Slow speed.
Manual via Lens Ring, Dual Pixel CMOS AF, Face Only, Face Priority
Manual via Iris Control Dial, Auto
f/2.8 - f/11 (AV Priority and Manual Modes)
58mm
14 groups of 18 elements (double aspherical lenses and single Hi-UD lenses)
9 Blades
Optical system (lens shift) + electronic stabilization
Dynamic, Powered IS, Standard
Yes. 300 X Digital Zoom, 2 X Digital Teleconverter.
Dual DIGIC DV6
12 stops (800%) in Wide DR mode
YCC 4:2:0
8 bit
Standard, Wide DR, Monochrome
SD / SDHC / SDXC card
Class U3 recommended for recording at 150MBPS
MP4 Recording: 150 Mbps: 55 Minutes. 35 Mbps: 240 Mins.
XF-AVC Recording: 160 Mbps: 50 Minutes. 45 Mbps: 185 Minutes.
FAT32/exFAT
MP4:
3840x2160 (150 Mbps) / 1920x1080 (35/17 Mbps) / 1280x720 (8/4 Mbps)
NTSC*: 59.94P / 29.97P / 23.98P
PAL: 50.00P/25.00P depending on recording resolution selected
XF-AVC:1
NTSC*:
3840 x 2160: 59.94P/ 29.97P/ 23.98P
1920 x 1080: 59.94P/ 59.94i/29.97P/23.98P/120P
1280 X 720: 59.94P/29.97P
PAL:
3840×2160: 50.00P/25.00P
1920×1080: 50.00P/50.00i/25.00P
1280×720: 50.00P/25.00P
SDI: XF405 Only
NTSC*:
1920x1080 59.94P YCC422 10bit /1920x1080 29.97P YCC422 10bit
PAL:
1920x1080 50.00P YCC422 10bit / 1920x1080 25.00P YCC422 10bit
HDMI: XF405 and XF400
NTSC*:
3840x2160 59.94P YCC420 8bit / 1920x1080 59.94P YCC422 10bit
3840x2160 29.97P YCC422 8bit / 1920x1080 29.97P YCC422 10bit
PAL:
3840x2160 50.00P YCC420 8bit / 1920x1080 50.00P YCC422 10bit
3840x2160 25.00P YCC422 8bit / 1920x1080 25.00P YCC422 10bit
50.00P/25.00P
Yes.
3840 x 2160: 50.00P: x2, x4, x10, x20, x60, x120, x600, x1200
25.00P: x0.5
1920 x 1080: 50.00P: x0.5, x2, x4, x10, x20, x60, x120, x600, x1200
25.00P: x0.25, x0.5
1280 x 720: 50.00P/8Mbps: x2, x4, x10, x20, x60, x120, x600, x1200
25.00P/4Mbps: x0.5
No
No
Yes. 3 Seconds
No
3840x2160 / 1920x1080 / 1280x720
(Still image resolution is dependent on the video resolution)
SD Card
MPEG-4 AAC-LC (16-bit 2CH) / LPCM (16-bit 4CH)
Manual or Auto
1KHz, -12dB / -18dB / -20dB / Off
Yes
LCD Capacitive touch panel
3.5-inch (8.9 cm)
(approx. 1.56 million dots)
Yes
No
Yes. Focus Guide Function in MF
Yes. Selectable Peaking Colour: Red / Blue / Yellow
Yes. 70%, 100%
Yes. Horizontal (grey) / Horizontal (white) / Grid (grey) / Grid (white)
0.24-inch
approx. 1.56 million dots
Yes
100%
+2.0 to -5 diopter
XLR 3-pin jacks (x2), balanced on Handle Unit. 3.5mm Stereo jack
(unbalanced) on camera body
Yes. 3.5mm
No
Yes
Yes. Mini-B and Hi-Speed USB supported
Yes. 3G-SDI Level A and B, selectable. BNC Connector (XF405 Only)
No. Timecode out via HDMI is possible
No
Yes. Ethernet connector (RJ45) (supports 1000 BASE-T)
No
Yes. 3.4mm Jack
Yes. 2.5mm mini jack
Yes, via third-party hardware or software decoding solution
Video Output: MPEG-4 AVC / H.264
PAL: 9Mbps / 4Mbps: 1920x1080 50.00i
Audio Output: MPEG-2 AAC-LC, 256 Kbps, 2 channels
Output CH: CH1 / CH2 / CH3 / CH4
UDP / RTP / RTP+FEC
Centre-weighted average metering: In the AUTO, P, Av, Tv, Portrait, Sports, Low Light
IR mode segment evaluative metering: Snow, Beach, Sunset, Spotlight, Night mode
No metering: Fireworks; Fixed exposure [1/60 sec. (PAL: 1/50 sec.)]
M (manual exposure)
Highlight AE, Exposure lock, Auto backlight compensation, Exposure compensation amount shown as ±3 when locked or ±2 in AUTO (±8 increments).
CP Files:
C1: Normal / C2: Wide DR / C3: Canon Log3
C4: EOS Std. / C5: USER 05 / C6: USER 06
Gamma / Colour Space:
BT.709 Wide DR / BT.709
CanonLog 3 / BT.709
EOS Std. / BT.709
BT.709 Normal / BT.709
BT.709 Standard / BT.709
Colour Matrix:
Neutral / Production Camera / EOS Std. / Video
P, Tv, Av, SCN (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks)
Yes
In manual exposure (P, Av, and Tv modes): 0-29 dB (in 1 dB increments)
Not wide DR mode, not S&F x 1/4: 0-29 dB (in 1 dB increments)
Not wide DR mode, S&F x 1/4: 9-29 dB (in 1 dB increments)
Wide DR mode, not S&F x 1/4: 9-29 dB (in 1 dB increments)
Wide DR mode, S&F x 1/4: 18-29 dB (in 1 dB increments)
M (Manual) shooting,
Not wide DR: 0-39 dB (1 dB increments)
Wide DR: 9 - 39 dB (1 dB increments)
Auto, Manual
Daylight: 5,600 K, Tungsten: 3,200, Default value for set 1,
set 2: 5,600 K Colour temperature (Kelvin) setting ranges from 2,000 K to 15,000 K.
Manual, Tv, Auto, P Mode
1/2 - 1/2000 sec
50.00P: Auto slow shutter On: 1/25 to 1/500 sec.
Auto slow shutter Off: 1/50 to 1/500 sec
25.00P: Auto slow shutter On: 1/12.5 to 1/500 sec. (Display is 1/12.)
Auto slow shutter Off: 1/25 to 1/500 sec.
No
Yes
Yes, in Handle Unit
Yes
EBU / SMPTE (PAL); SMPTE / ARIB (NTSC*)
Cold Shoe
Yes. 5 assignable buttons.
Push Auto Iris / Zebra 70% / Zebra 100% / BLC Always On / Face Only AF / AF Frame/ Peaking/ Focus Guide / WB/ Set WB / WB Priority / Digital Tele Converter / IR Light / Slow and Fast Motion / Monitor Channels / Marker / Menu / Custom Picture / AF / MF / Powered IS / Pre Rec / Rec Review / Magnification / Photo / Off
Yes. [Av / Tv / M] / Exposure Compensation / AGC Limit / Off
IEEE802.11b/g/n/a (2.4 GHz/5 GHz)
Browser Remote (Camera Mode)/FTP file transfer (Media Mode)
Internet Explorer 8 or later, Safari (iOS 9 or 10), Safari (MacOS), Android standard browser Andoid 4.4 - 6.0
(1) Aperture (including ND control)
(2) Focus The amount by which the focus is driven toward NEAR and toward FAR can each be controlled in 3 steps.
(3) White balance
(4) Shutter speed
(5) Gain
(6) Exposure compensation
(7) Shooting mode
(8) Zooming and SLOT SELECT control can be exercised. The free memory remaining on the media, time code, remaining battery charge, etc. can be checked. Live View.
Camera setting mode: 680 x 383
Simplified setting mode: 284 x 160
When Wi-Fi has been set manually in the XF405/XF400 select
“Open Encoding,” “Open WEP,” “Shared key/WEP”, “WPA, WPA2-PSK,” or “WPA2-PSK AES.”
(*) At the WPS setting stage, the settings are established automatically according to the authentication and encryption systems set at the access point.
Location (latitude, longitude and altitude) as well as the GPS
information while using Coordinated Universal Time (UTC) can be added to MP4 movies and photos. Also, based on this information, the satellite data acquisition status can be checked in camera mode.
Rec Run / Free Run
00:00:00:00 - 23:59:59:29 (PAL 23:59:59:24)
DF / NDF
Setting (00 00 00 00 - FF FF FF FF) / Time / Date
Lens hood with barrier, Mic holder unit (w/ screw), Handle unit, Wireless Controller (WL-D89), Lithium battery (CR2025), AC adapter (CA-946), Battery Pack BP-828, AC Cable, Lens Cap
Canon Battery Pack BP-820/BP-828
Canon AC Adapter CA-946 (included with XF405/XF400)
Canon Battery Charger CG-800/CG-800E, Canon High speed HDMI cable HTC-100, Canon High speed HDMI cable HTC-100/ High speed HDMI cable HTC-100/S, Canon Wireless Controller WL-D89, * Canon Tele Converter TL-U58 * Canon Wide Attachment WA-U58
Canon Soft Carrying Case SC-1000, SC-2000
Canon Wrist Strap WS-20,Canon Shoulder Strap SS-600/650
Canon PROTECT filter 58 mm, Canon ND4-L filter 58 mm
Canon ND8-L filter 58 mm, Canon GPS Receiver GP-E2
Canon Remote Controller RC-V100, Canon Battery Video Light VL-10Li/VL-10LiII Canon Battery Pack BP-900 series (for VL-10Li/VL-10LiII), Canon Compact Power Adapter CA910/920/930 (charges BP-900 series battery packs), Canon Car Battery Adapter CB-910/920 (for charging the BP-900 series), Canon Interface Cable IFC-300PCU/S / IFC-400PCU
8.4W (MP4, 3840 x 2160, 50.00P Panel in use)
Canon Battery Pack BP-828 (supplied) BP-820 (Optional)
BP-828: 125 mins (MP4, 3840 x 2160, 50.00P Panel in use)
Approx. 150 x 216 x 267 mm (approx. 5.9 x 8.5 x 10.5 in.)
[Including lens hood, BP-828, mic holder unit, and handle unit]
XF405: 1150g(2.5 lb) XF400: 1145g (2.5lb)
XF405:1670g (3.7lb) XF400: 1665g (3.7lb)
Camera, Lens Hood, Handle Unit, BP-828 batery, 1 SD card
Approx. 0 to 40 °C, 85 % (relative humidity)
Approx. -5 to 45 °C, 60 % (relative humidity)
*PAL version only sold within EMEA region. However, customers may have NTSC option activated via a paid for upgrade at a Canon Authorised Service Centre
All specifications are subject to change without notice
